Volkswagen Golf Mk7 Owners Manual: Side view
Fig. 1 is the labelled side profile of the Volkswagen Golf Mk7, keying every exterior fitting a driver is likely to ask about: the roof aerial, the fuel tank flap, the exterior door release lever, the exterior mirrors, an additional turn signal repeater, the sill surround lighting, and the front and rear jacking points used when changing a wheel. Cross-reference the numbered key against the diagram to locate a specific part before jumping to its dedicated how-to section.
Fig. 1 Overview of the driver side
Key for :
Roof aerial
Tank flap
Exterior door release lever
Exterior mirrors
- Additional turn signal
- Surround lighting
Jacking points
